    Pathway Description
      ADP-L-glycero-beta-D-manno-heptose Biosynthesis
Escherichia coli
          Metabolic Pathway


          ADP-L-glycero-β-D-manno-heptose is a precursor for the inner core lipopolysaccharide (LPS), which is the outer membrane of Gram-negative bacteria. LPS is consisted of lipid A, a core oligosaccharide, and an O-specific polysaccharide (O antigen). This biosynthesis pathway starts with catalyzation of D-sedoheptulose 7-phosphate that produced from pentose phosphate pathway to form D-glycero-D-manno-heptose 7-phosphate by lysophospholipid acyltransferase. D-glycero-D-manno-heptose 7-phosphate later undergoes catalyze to form D-glycero-β-D-manno-heptose 1,7-bisphosphate by fused heptose 7-phosphate kinase (also known as heptose 1-phosphate adenyltransferase) that powered by ATP. D-glycero-β-D-manno-heptose 1,7-bisphosphate will go through hydrolysis by D,D-heptose 1,7-bisphosphate phosphatase to form D-glycero-β-D-manno-heptose 1-phosphate and a phosphate. D-glycero-β-D-manno-heptose 1-phosphate will form ADP-D-Glycero-D-manno-heptose and diphosphate, and eventually ADP-D-Glycero-D-manno-heptose will be biotransformed to ADP-L-glycero-β-D-manno-heptose as the end product of this pathway by ADP-L-glycero-D-mannoheptose-6-epimerase.

      References

      ADP-L-glycero-beta-D-manno-heptose Biosynthesis References
Kneidinger B, Marolda C, Graninger M, Zamyatina A, McArthur F, Kosma P, Valvano MA, Messner P: Biosynthesis pathway of ADP-L-glycero-beta-D-manno-heptose in Escherichia coli. J Bacteriol. 2002 Jan;184(2):363-9.
                  Pubmed: 11751812
              This pathway was propagated using PathWhiz -
                Pon, A. et al. Pathways with PathWhiz (2015) Nucleic Acids Res. 43(Web Server issue): W552–W559.

            Propagated from PW002095
