Pathway Description
Phospholipid Biosynthesis CL(18:1(9Z)/14:0/14:0/14:0)
Escherichia coli
Metabolic Pathway
Phospholipids are membrane components in E. coli.
The major phospholipids of E. coli are phosphatidylethanolamine, phosphatidylglycerol and cardiolipin. All phospholipids contain sn-glycerol-3-phosphate esterified with fatty acids at the sn-1 and sn-2 positions.
The reaction starts from a glycerone phosphate (dihydroxyacetone phosphate) produced in glycolysis. The glycerone phosphate is transformed to a sn-glycerol 3-phosphate (glycerol 3 phosphate) by NADPH driven glycerol-3-phosphate dehydrogenase.
Sn-glycerol 3-phosphate is transformed to a 1-acyl-sn-glycerol 3-phosphate(1-oleyl-2-lyso-phosphatidate , 1-palmitoylglycerol 3-phosphate , 1-stearoyl-sn-glycerol 3-phosphate). This can be achieve by a sn-glycerol-3-phosphate 1-0-acyltransferase that interacts either with a long-chain acyl-CoA or with an acyl-[acp]. The 1-acyl-sn-glycerol 3-phosphate is transformed into a 1,2-diacyl-sn-glycerol 3-phosphate through a 1-acylglycerol-3-phosphate O-acyltransferase.
This compound is then converted into a CPD-diacylglycerol through a CTP (phosphatidate cytididyltransferase. CPD-diacylglycerol can be transformed either to a L-1-phosphatidylserine or a L-1-phosphatidylglycerol-phosphate through a phosphatidylserine synthase or a phosphatidylglycerophosphate synthase respectively. The L-1-phosphatidylserine transforms into L-1-phosphatidylethanolamine through a phosphatidylserine decarboxylase, o the other hand L-1-phosphatidylglycerol-phosphate gets transformed into a L-1-phosphatidyl-glycerol through a phosphatidylglycerophosphatase. These 2 products combines produce a cardiolipin and a ethanolamine.
The L-1 phosphatidyl-glycerol can also interact with cardiolipin synthase resulting in a glycerol and a cardiolipin.
References
Phospholipid Biosynthesis CL(18:1(9Z)/14:0/14:0/14:0) References
Cronan JE Jr, Rock CO: Biosynthesis of Membrane Lipids. EcoSal Plus. 2008 Sep;3(1). doi: 10.1128/ecosalplus.3.6.4.
Pubmed: 26443744
This pathway was generated using PathWhiz -
Pon, A. et al. Pathways with PathWhiz (2015) Nucleic Acids Res. 43(Web Server issue): W552–W559.
Generated from PW001001
