Pathway Description
Purine Ribonucleosides Degradation
Escherichia coli
Metabolic Pathway
Purine ribonucleoside degradation leads to the production of alpha-D-ribose-1-phosphate.
Xanthosine is transported into the cytosol through a xapB. Once in the cytosol xanthosine interacts with phosphate through a xanthosine phosphorylase resulting in the release of a xanthine and a alpha-D-ribose-1-phosphate.
Adenosine is transported through a nupC or a nupG transporter, once inside the cytosol it can either react with a phosphate through a adenosine phosphorylase resultin in the release of a adenine and an alpha-D-ribose-1-phosphate. Adenosine reacts with water and hydrogen ion through a adenosine deaminase resulting in the release of ammonium and inosine. Inosine reacts with phosphate through a inosine phosphorylase resulting in the release of a hypoxanthine and an alpha-D-ribose-1-phosphate.
Guanosine reacts with a phosphate through a guanosine phosphorylase resulting in the release of a guanine and a alpha-D-ribose-1-phosphate.
References
Purine Ribonucleosides Degradation References
Neidhardt FC, Curtiss III R, Ingraham JL, Lin ECC, Low Jr KB, Magasanik B, Reznikoff WS, Riley M, Schaechter M, Umbarger HE. Escherichia coli and Salmonella, Cellular and Molecular Biology, Second Edition. American Society for Microbiology, Washington, D.C., 1996.
